2021/08/28

Flirc Raspberry Pi 4 Case heat test

 I recently got a Flirc case for my Raspberry Pi4 and was unsure if it would help the temperature of the CPU under a heavy load. So after reading mixed impressions of similar cases with builtin heatsinks on the internet, I decided I needed to run my own tests.

TLDR; It's a good looking case that keeps the temperature low enough and Wifi still works well.

You can see in the chart that in the first test the Pi without a case is warmer at idle and hits the throttling above 83º but in the second test after installing the Pi in the case the idle temperature is lower and the peak is about 60º. And yes, it took about 7 minutes to install it in the case and reboot.


Clearly the case kept the Pi cooler which was great! The case has a solid metal top that acts as a heatsink with a black plastic cover on the top and bottom. I also wondered if the plastic cover on the top reduced the heat dissipation, so I ran the test again and found that it made no noticeable difference. So I'm keeping the plastic on top.

Here is the test setup using Graphite/Grafana on my Pi to chart the temperature.

1. add a cron script to write the Pi temp to Graphite every minute.

#!/bin/sh

# Track the PI core temp in graphite

# whisper files are in /var/lib/graphite/whisper/

CARBON_PORT=2003

CARBON_SERVER=localhost

CARBON_PREFIX=pi

DATE=`date +%s`

VALUE=`/opt/vc/bin/vcgencmd measure_temp | egrep -o '[0-9]*\.[0-9]*'`

echo "$CARBON_PREFIX.temp $VALUE $DATE" | nc -N ${CARBON_SERVER} ${CARBON_PORT}

exit $?

2. install the load tester that will warm up all 4 of the CPU cores

sudo apt install stress-ng

3. the 10 minute stress test command

sudo stress-ng --cpu 0 --cpu-method fft -t 600 --times --tz --perf

The results without a case had fewer CPU cycles due to the throttling.

stress-ng: info:  [26124] dispatching hogs: 4 cpu

stress-ng: info:  [26124] cache allocate: using defaults, can't determine cache details from sysfs

stress-ng: info:  [26124] successful run completed in 600.88s (10 mins, 0.88 secs)

stress-ng: info:  [26124] cpu:

stress-ng: info:  [26124]          3,351,213,272,324 CPU Cycles                      5.58 B/sec

stress-ng: info:  [26124]          5,257,128,421,496 Instructions                    8.75 B/sec (1.569 instr. per cycle)

stress-ng: info:  [26124]              2,355,284,116 Branch Misses                   3.92 M/sec ( 0.00%)

stress-ng: info:  [26124]          1,117,147,979,068 Bus Cycles                      1.86 B/sec

stress-ng: info:  [26124]          1,925,684,309,644 Cache References                3.20 B/sec

stress-ng: info:  [26124]             70,192,888,528 Cache Misses                    0.12 B/sec ( 3.65%)

stress-ng: info:  [26124]          1,925,714,318,612 Cache L1D Read                  3.20 B/sec

stress-ng: info:  [26124]             70,209,791,620 Cache L1D Read Miss             0.12 B/sec

stress-ng: info:  [26124]            601,769,965,280 Cache L1D Write                 1.00 B/sec

stress-ng: info:  [26124]             39,275,045,820 Cache L1D Write Miss           65.36 M/sec

stress-ng: info:  [26124]          1,623,493,004,028 Cache L1I Read                  2.70 B/sec

stress-ng: info:  [26124]                237,104,488 Cache L1I Read Miss             0.39 M/sec

stress-ng: info:  [26124]             11,372,158,076 Cache DTLB Read Miss           18.93 M/sec

stress-ng: info:  [26124]              6,457,277,064 Cache DTLB Write Miss          10.75 M/sec

stress-ng: info:  [26124]                  3,019,056 Cache ITLB Read Miss            5.02 K/sec

stress-ng: info:  [26124]            680,066,666,288 Cache BPU Read                  1.13 B/sec

stress-ng: info:  [26124]              2,355,275,308 Cache BPU Read Miss             3.92 M/sec

stress-ng: info:  [26124]              1,316,252,132 Cache NODE Read                 2.19 M/sec

stress-ng: info:  [26124]                629,580,520 Cache NODE Write                1.05 M/sec

stress-ng: info:  [26124]          2,311,855,064,928 CPU Clock                       3.85 B/sec

stress-ng: info:  [26124]          2,311,958,359,704 Task Clock                      3.85 B/sec

stress-ng: info:  [26124]                        156 Page Faults Total               0.26 /sec

stress-ng: info:  [26124]                        156 Page Faults Minor               0.26 /sec

stress-ng: info:  [26124]                          0 Page Faults Major               0.00 /sec

stress-ng: info:  [26124]                    130,392 Context Switches              217.00 /sec

stress-ng: info:  [26124]                        916 CPU Migrations                  1.52 /sec

stress-ng: info:  [26124]                          0 Alignment Faults                0.00 /sec

stress-ng: info:  [26124]                          0 Emulation Faults                0.00 /sec

stress-ng: info:  [26124]                        376 System Call Enter               0.63 /sec

stress-ng: info:  [26124]                        372 System Call Exit                0.62 /sec

stress-ng: info:  [26124]                      1,288 Kmalloc                         2.14 /sec

stress-ng: info:  [26124]                          0 Kmalloc Node                    0.00 /sec

stress-ng: info:  [26124]                      4,920 Kfree                           8.19 /sec

stress-ng: info:  [26124]                      7,924 Kmem Cache Alloc               13.19 /sec

stress-ng: info:  [26124]                          0 Kmem Cache Alloc Node           0.00 /sec

stress-ng: info:  [26124]                     21,684 Kmem Cache Free                36.09 /sec

stress-ng: info:  [26124]                        496 MM Page Alloc                   0.83 /sec

stress-ng: info:  [26124]                      2,496 MM Page Free                    4.15 /sec

stress-ng: info:  [26124]                  1,481,552 RCU Utilization                 2.47 K/sec

stress-ng: info:  [26124]                        732 Sched Migrate Task              1.22 /sec

stress-ng: info:  [26124]                          0 Sched Move NUMA                 0.00 /sec

stress-ng: info:  [26124]                    127,900 Sched Wakeup                  212.86 /sec

stress-ng: info:  [26124]                          0 Sched Proc Exec                 0.00 /sec

stress-ng: info:  [26124]                          0 Sched Proc Exit                 0.00 /sec

stress-ng: info:  [26124]                          0 Sched Proc Fork                 0.00 /sec

stress-ng: info:  [26124]                        136 Sched Proc Free                 0.23 /sec

stress-ng: info:  [26124]                          0 Sched Proc Hang                 0.00 /sec

stress-ng: info:  [26124]                          0 Sched Proc Wait                 0.00 /sec

stress-ng: info:  [26124]                    130,392 Sched Switch                  217.00 /sec

stress-ng: info:  [26124]                          4 Signal Generate                 0.01 /sec

stress-ng: info:  [26124]                          4 Signal Deliver                  0.01 /sec

stress-ng: info:  [26124]                    710,424 IRQ Entry                       1.18 K/sec

stress-ng: info:  [26124]                    710,424 IRQ Exit                        1.18 K/sec

stress-ng: info:  [26124]                     84,488 Soft IRQ Entry                140.61 /sec

stress-ng: info:  [26124]                     84,488 Soft IRQ Exit                 140.61 /sec

stress-ng: info:  [26124]                          0 Writeback Dirty Inode           0.00 /sec

stress-ng: info:  [26124]                          0 Writeback Dirty Page            0.00 /sec

stress-ng: info:  [26124]                          0 Migrate MM Pages                0.00 /sec

stress-ng: info:  [26124]                      3,304 SKB Consume                     5.50 /sec

stress-ng: info:  [26124]                      1,016 SKB Kfree                       1.69 /sec

stress-ng: info:  [26124] cpu:

stress-ng: info:  [26124]          cpu-thermal   82.05 °C

stress-ng: info:  [26124] for a 600.88s run time:

stress-ng: info:  [26124]    2403.51s available CPU time

stress-ng: info:  [26124]    2310.76s user time   ( 96.14%)

stress-ng: info:  [26124]       4.64s system time (  0.19%)

stress-ng: info:  [26124]    2315.40s total time  ( 96.33%)

stress-ng: info:  [26124] load average: 4.24 3.60 2.36


The results with the case

stress-ng: info:  [2458] dispatching hogs: 4 cpu

stress-ng: info:  [2458] cache allocate: using defaults, can't determine cache details from sysfs

stress-ng: info:  [2458] successful run completed in 600.89s (10 mins, 0.89 secs)

stress-ng: info:  [2458] cpu:

stress-ng: info:  [2458]          3,466,468,096,172 CPU Cycles                      5.77 B/sec

stress-ng: info:  [2458]          5,433,442,835,240 Instructions                    9.04 B/sec (1.567 instr. per cycle)

stress-ng: info:  [2458]              2,428,481,032 Branch Misses                   4.04 M/sec ( 0.00%)

stress-ng: info:  [2458]          1,155,591,178,712 Bus Cycles                      1.92 B/sec

stress-ng: info:  [2458]          1,990,529,210,212 Cache References                3.31 B/sec

stress-ng: info:  [2458]             72,971,962,212 Cache Misses                    0.12 B/sec ( 3.67%)

stress-ng: info:  [2458]          1,990,582,334,864 Cache L1D Read                  3.31 B/sec

stress-ng: info:  [2458]             72,956,292,228 Cache L1D Read Miss             0.12 B/sec

stress-ng: info:  [2458]            621,927,779,860 Cache L1D Write                 1.04 B/sec

stress-ng: info:  [2458]             40,460,573,360 Cache L1D Write Miss           67.33 M/sec

stress-ng: info:  [2458]          1,667,242,631,912 Cache L1I Read                  2.77 B/sec

stress-ng: info:  [2458]                232,913,956 Cache L1I Read Miss             0.39 M/sec

stress-ng: info:  [2458]             11,851,802,864 Cache DTLB Read Miss           19.72 M/sec

stress-ng: info:  [2458]              6,597,373,720 Cache DTLB Write Miss          10.98 M/sec

stress-ng: info:  [2458]                  3,412,088 Cache ITLB Read Miss            5.68 K/sec

stress-ng: info:  [2458]            702,798,169,272 Cache BPU Read                  1.17 B/sec

stress-ng: info:  [2458]              2,428,041,468 Cache BPU Read Miss             4.04 M/sec

stress-ng: info:  [2458]                866,617,940 Cache NODE Read                 1.44 M/sec

stress-ng: info:  [2458]                331,821,000 Cache NODE Write                0.55 M/sec

stress-ng: info:  [2458]          2,321,089,381,860 CPU Clock                       3.86 B/sec

stress-ng: info:  [2458]          2,321,181,986,648 Task Clock                      3.86 B/sec

stress-ng: info:  [2458]                        156 Page Faults Total               0.26 /sec

stress-ng: info:  [2458]                        156 Page Faults Minor               0.26 /sec

stress-ng: info:  [2458]                          0 Page Faults Major               0.00 /sec

stress-ng: info:  [2458]                    108,616 Context Switches              180.76 /sec

stress-ng: info:  [2458]                        776 CPU Migrations                  1.29 /sec

stress-ng: info:  [2458]                          0 Alignment Faults                0.00 /sec

stress-ng: info:  [2458]                          0 Emulation Faults                0.00 /sec

stress-ng: info:  [2458]                        376 System Call Enter               0.63 /sec

stress-ng: info:  [2458]                        372 System Call Exit                0.62 /sec

stress-ng: info:  [2458]                      1,476 Kmalloc                         2.46 /sec

stress-ng: info:  [2458]                          0 Kmalloc Node                    0.00 /sec

stress-ng: info:  [2458]                      7,296 Kfree                          12.14 /sec

stress-ng: info:  [2458]                     13,092 Kmem Cache Alloc               21.79 /sec

stress-ng: info:  [2458]                          0 Kmem Cache Alloc Node           0.00 /sec

stress-ng: info:  [2458]                     27,704 Kmem Cache Free                46.10 /sec

stress-ng: info:  [2458]                        648 MM Page Alloc                   1.08 /sec

stress-ng: info:  [2458]                      4,620 MM Page Free                    7.69 /sec

stress-ng: info:  [2458]                  1,485,888 RCU Utilization                 2.47 K/sec

stress-ng: info:  [2458]                      1,348 Sched Migrate Task              2.24 /sec

stress-ng: info:  [2458]                          0 Sched Move NUMA                 0.00 /sec

stress-ng: info:  [2458]                    107,156 Sched Wakeup                  178.33 /sec

stress-ng: info:  [2458]                          0 Sched Proc Exec                 0.00 /sec

stress-ng: info:  [2458]                          0 Sched Proc Exit                 0.00 /sec

stress-ng: info:  [2458]                          0 Sched Proc Fork                 0.00 /sec

stress-ng: info:  [2458]                        228 Sched Proc Free                 0.38 /sec

stress-ng: info:  [2458]                          0 Sched Proc Hang                 0.00 /sec

stress-ng: info:  [2458]                          0 Sched Proc Wait                 0.00 /sec

stress-ng: info:  [2458]                    108,616 Sched Switch                  180.76 /sec

stress-ng: info:  [2458]                          0 Signal Generate                 0.00 /sec

stress-ng: info:  [2458]                          4 Signal Deliver                  0.01 /sec

stress-ng: info:  [2458]                    702,072 IRQ Entry                       1.17 K/sec

stress-ng: info:  [2458]                    702,072 IRQ Exit                        1.17 K/sec

stress-ng: info:  [2458]                    115,840 Soft IRQ Entry                192.78 /sec

stress-ng: info:  [2458]                    115,840 Soft IRQ Exit                 192.78 /sec

stress-ng: info:  [2458]                          0 Writeback Dirty Inode           0.00 /sec

stress-ng: info:  [2458]                          0 Writeback Dirty Page            0.00 /sec

stress-ng: info:  [2458]                          0 Migrate MM Pages                0.00 /sec

stress-ng: info:  [2458]                      3,436 SKB Consume                     5.72 /sec

stress-ng: info:  [2458]                      1,148 SKB Kfree                       1.91 /sec

stress-ng: info:  [2458] cpu:

stress-ng: info:  [2458]          cpu-thermal   59.77 °C

stress-ng: info:  [2458] for a 600.89s run time:

stress-ng: info:  [2458]    2403.56s available CPU time

stress-ng: info:  [2458]    2315.14s user time   ( 96.32%)

stress-ng: info:  [2458]       3.44s system time (  0.14%)

stress-ng: info:  [2458]    2318.58s total time  ( 96.46%)

stress-ng: info:  [2458] load average: 4.00 3.59 2.04


That's it.
